Temporary Single Head Conductor Transmission Line Tool / Cable Sleeve Mesh Sock Joint

Temporary Single Head Conductor Transmission Line Tool / Cable Sleeve Mesh Sock Joint
Temporary Single Head Conductor Transmission Line Tool / Cable Sleeve Mesh Sock Joint Temporary Single Head Conductor Transmission Line Tool / Cable Sleeve Mesh Sock Joint Temporary Single Head Conductor Transmission Line Tool / Cable Sleeve Mesh Sock Joint

Large Image :  Temporary Single Head Conductor Transmission Line Tool / Cable Sleeve Mesh Sock Joint

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: SLW
Payment & Shipping Terms:
Minimum Order Quantity: 2SETS
Price: GET THE LATEST
Packaging Details: WOODEN CASE
Delivery Time: 5-8WORK DAYS
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000SETS/WEEK
Detailed Product Description
APPROVED: ISO CE MODEL: SLW-2
ACSR DIA: 120-150 RATED LOAD: 20KN
BREAKING: 40KN FEATURE: ONE OR TWO HEAD
High Light:

transmission line tool

,

cable pulling tools

Single Head Conductor Mesh Sock Joints Cable Sleeve Mesh Sock Joint



ONE HEAD TYPE

The one head type temporary mesh sock joints are specifically designed to temporarily connect the aluminum, steel, or copper conductor to the pulling rope. They consist of variable pitch steel wires, which effectively distribute the gripping effect on the conductor.



Model Conductor size (mm2) Rated load (kN) Breaking load (kN)
SLW-1 25-70 10 20
SLW-1.5 70~90 15 30
SLW-2 120~150 20 40
SLW-2.5 185~240 25 50
SLW-3 300~400 30 60
SLW-4 500~630 40 80
SLW-5 720 50 125
SLW-7 900 70 175
SLW-8 1000~1120 80 200



Features:

1.It made of top-quality steel through heat treatment and galvanized for surface.

2.It connected for two head,one head is galvanized steel wire rope and the other head contect conductor.

Application:It is used for connecting and holding firmly conductor.



Cable Mesh Sock Joints



Item number



Model

(MM)

Applicable

Cable Diameter

(KN)

Rated Load

(Kg)

Weight

21361 SWL-16 Φ12-16 10 0.8
21362.8 SWL-20 Φ16-20 10 0.8
21363 SWL-25 Φ20-25 15 1.0
21364 SWL-37 Φ25-37 15 1.0
21365 SWL-50 Φ37-50 15 1.0
21366` SWL-60 Φ50-60 25 2.4
21367 SWL-80 Φ60-80 25 2.4
21368 SWL-100 Φ80-100 25 2.4
21369 SWL-120 Φ100-120 30 2.6
21370 SWL-150 Φ120-150 30 2.6

Configuration:

◆ Apply to installing electrcity cable communication cable and normal cable.

Temporary Single Head Conductor Transmission Line Tool / Cable Sleeve Mesh Sock Joint 0Temporary Single Head Conductor Transmission Line Tool / Cable Sleeve Mesh Sock Joint 1
