Output 20T Width 150mm Underground Cable Tools Hydraulic Busbar Cutter

Output 20T Width 150mm Underground Cable Tools Hydraulic Busbar Cutter
Output 20T Width 150mm Underground Cable Tools Hydraulic Busbar Cutter Output 20T Width 150mm Underground Cable Tools Hydraulic Busbar Cutter

Large Image :  Output 20T Width 150mm Underground Cable Tools Hydraulic Busbar Cutter

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO
Model Number: CWC
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: get the latest
Packaging Details: wooden case
Delivery Time: 2-4work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200sets/day
Detailed Product Description
Model: CWC150 Cutting Force: 20T
Max Thicknedd: Cu/Al Plate 10mm Width: 150mm
Height: Approx 440mm Packing: Wooden Case
High Light:

hydraulic cable crimping tool

,

hydraulic crimping tool for electrical cables

Output 20T Width 150mm Max thickness 10mm Model CWC Hydraulic Bus Bar Cutter for Cutting



Application

Portable Model CWC Hydraulic Bus Bar Cutter For Cutting is formed by high strength alloy steel precision.It is high efficacy due to smooth fracture surface and neat without burrs. It only takes a few seconds to cut off the Angle. It is mainly used in the iron tower factory, cutting off in transmission and distribution engineering construction site.

Hydraulic Copper Aluminum Bus-bar Cutter

Item number

06242-1 06242-1A
Model CWC-150 CWC-200



Cutting force

200KN 300KN

Max thickness

of sheet

CU/AL plate 10mm 12mm

Width of sheet

CU/AL plate 150mm

200mm

Height

approx.440mm approx.460mm

(KG)

Weight

approx.N.W30KG

G.W33KG

approx.N.W37KG

G.W40KG

Package

wooden case wooden case

Configuration: It is used to cut off the copper and aluminum platoon,and thehydraulic pump needs to be matched.
